Air Handling Unit

Slider Image
Slider Thumb

A Double Skin Air Handling Unit (AHU) is a premium HVAC system engineered to deliver superior indoor air quality through controlled ventilation, filtration, heating, and cooling functions. It features a two-layer (inner and outer) panel construction with insulation in between, which significantly reduces thermal bridging, noise levels, and energy loss. These units are designed to withstand diverse environmental conditions while ensuring stable airflow and optimal temperature control. With modular construction, high-efficiency components, and customizable configurations, Double Skin AHUs are widely used in environments that demand stringent air purity, consistent climate control, and reliable performance. Their robust build and energy-efficient design make them suitable for continuous operation in industrial, commercial, and cleanroom facilities.

Cheque,NEFT And RTGS

Key Attributes
Industry-specific Attributes
  • Casing Construction Double skin with PUF / Rockwool insulation
  • Insulation Thickness 25–50 mm (as required)
  • Panel Material Galvanized Steel / Aluminium / Pre-coated Sheet
  • Frame Structure Thermal break aluminium / GI profile
  • Airflow Capacity 1,000 CFM – 60,000+ CFM
  • Fan Type EC/Plug Fan or Centrifugal Fan
Other Attributes
  • Motor Type Direct drive / Belt drive
  • Filter Types Pre-Filter, Fine Filter, HEPA (optional)
  • Noise Level Low noise due to insulated casing
  • Mounting Floor-mounted / ceiling-suspended
  • Application Area Commercial, industrial, cleanroom, healthcare
Slider Image
Slider Thumb

An Air Handling Unit (AHU) Panel is a centralized control system designed to operate, regulate, and safeguard the performance of an AHU within an HVAC network. It houses controllers, sensors, starters, relays, and monitoring interfaces that work together to ensure efficient airflow, temperature control, and humidity management. The AHU panel continuously processes data from sensors to adjust fan speeds, damper positions, and heating/cooling operations for optimal indoor conditions. Safety features like overload protection, alarms, and fault diagnostics ensure reliable operation. PLC automation and BMS compatibility make it ideal for industrial, commercial, and controlled environments requiring precise climate management.

Cheque,NEFT And RTGS

Key Attributes
Industry-specific Attributes
  • Material Stainless Steel
  • Voltage Rating 220V Electric Supply
  • Mounting Type Floor Stand
  • Panel Thickness 3 mm
  • Shape Rectangle
  • Control System Microcontroller or PLC for automation
  • User Interface LCD / Touchscreen for real-time monitoring
Other Attributes
  • Sensor Integration Temperature and humidity sensors
  • Fan Control Supply and return fan start/stop, speed regulation, motor protection
  • Damper Control Fresh air, exhaust, and return air dampers with motorized operation
  • Temperature & Humidity Management Coordinates with cooling coils, heaters, and valves
  • Safety Features Overload, short circuit protection, alarms, and fault indication
  • BMS Integration Supports communication for building management system
  • Energy Efficiency Programmable schedules, VFD compatibility, optimized control logic
